Recommended Starting Laser Settings
IMPORTANT: Laser settings are provided as starting points only and may not produce the desired results on every machine or material. Always test before engraving your final product. The Laser Outpost is not responsible for engraving outcomes or damaged products. Refunds or replacements will not be issued for engraving-related damage.
Swipe left to view more settings →
| Laser Machine | Source | Material / Color | Power | Speed (mm/s) | Passes | LPC/LI | Freq. | Angle | Crosshatch | Notes |
|---|---|---|---|---|---|---|---|---|---|---|
| xTool F1 | IR | Stainless Steel - All Finishes Except Black | 100% | 3 | 1 | 200 | — | — | — | — |
| xTool F1 | IR | Stainless Steel - Black Engraves Silver | 30% | 50 | 1 | 220 | — | — | — | — |
| xTool F2 | IR | Stainless Steel - All FInishes Except Black | 100% | 25 | 1 | 280 | — | — | — | — |
| xTool F2 Ultra | Mopa IR | Stainless Steel - Black Engraves Silver | 40% | 3200 | 1 | 200 | 60 | — | — | Pulse Width 500 |
| xTool F2 Ultra UV | Engrave | Stainless Steel - All Finishes Except Black | 70% | 300 | 4 | 800 | 40 | — | — | Defocus Distance 3mm |
Important: Always test on a sample before engraving your final product.
